Poultry Farms Pan Feeder System Chicken Breeding

Basic Information
Place of Origin: China
Brand Name: XDA
Model Number: XDA-F01
Minimum Order Quantity: 1set
Price: 1000 -5000 USD
Packaging Details: Standard
Delivery Time: 15 - 30 days
Payment Terms: L/C, T/T
Supply Ability: 10 houses per month
Detail Information
Type: Fully Automatic Feed System Application: Poultry Farm Shed
Voltage: 1-phase 110V/220V, 3 Phase 220V/380V Advantage: Long Life
Drive Motor: 0.75kW, 1.1kW, 1.5kW Applicable: Poultry Farm Shed
Whatsapp: 008618830728667
High Light:

poultry farms pan feeder system


chicken breeding pan feeder system

Product Description

Poultry farms chicken breeding pan feeding system floor husbandry broiler feeding line equipment




High-quality special driving motor Italy Transtechno
Power: 0.75kw, voltage: 380V, frequency: 50HZ, three-phase AC current
V-shaped Bin (With Hopper)
Bin Volume: 115L, hopper volume: 38L, Material: hot-dip galvanized sheet
Feeding Pipe
3m 4holes
Diameter: φ45mm
Material: Quality hot-dip galvanized steel pipe with the zinc coating amount of more than 275g/m2
South African Auger
Feeding Capacity: 450kg/h
Germany Capacitive Level Sensor
Time delay range 0 to 2 hours
Hanging System
All the required parts including the winches




Consists of a driving device, a hopper, a conveying pipe, an auger, trays, a suspension lifting device, an anti-perching device, and a feed sensor. The main function of the system is to convey the feed in the hopper into each tray to ensure the eating of the broiler and automatically control the conveying opening/closing of the motor by the material level sensor to feed automatically.



Volume: 600kg 800kg 1200kg

driving motor:

power:0.75kw/1.1kw/1.5kw voltage:0.75kw/1.1kw/1.5kw Frequency:50hz/60hz, 3phase/1phase

Feed sensor: IFM brand from Germany.


2.Automatic Pan Feeding Line System

The feed in the silo is transported to the hopper of the feed line,And the transmission closure of the driving motor is controlled by the feed level sensor.

TubeΦ45mm diameter

material:hot-dip galvanized steel pipe with the zinc coating amount of more than 275/m2

Auger: Helical spring auger imported from South Africa,

Feeding ability:450kg/h

Pan Feeder4 pans/3 meters, 3 pans/3 meters.

Feed Sensor: IFM from Germany, time delay range 0 to 2 hours.

when feed sensor is installed inside the feed pan(connect to open),driving motor starts work to convey feed , when feed sensor dose not touch feed,and it shops conveying feed when feed sensor touchs feed (for main feed line and pan feeding line use)


feed pan

feedpan slide switch could adjust feed flow until it is filled.

pan bottom can be disassembled on the ground,working for day-old chicken.

V-pan place design can reduce feed storage on bottom, so birds can always eat fresh feed. the design can also prevent birds from staying too long on the plate.

the edge of pan plate tilt towords the center, which can avoid waste of food.

thesmooth edge can prevent the craw of birds from hurting and make sure safety and comfort feeding.

feed pan installation has fixed type or swing type.

System Pictures:

Poultry Farms Pan Feeder System Chicken Breeding 0Poultry Farms Pan Feeder System Chicken Breeding 1
