Broiler Automatic Feeder Chicken Breeding Equipment

Basic Information
Place of Origin: China
Brand Name: XDA
Model Number: XDA-F03
Minimum Order Quantity: 1 house
Price: 5000 - 30000 USD
Packaging Details: Standard
Delivery Time: 15 - 30 days
Payment Terms: L/C, T/T
Supply Ability: 10 houses per month
Detail Information
Name: Female Male Parent Breeder Farming House Life Span: Over 10 Years
Breeder Feeder: 8-9 Males/feed Pan Breeder Drinker: 8-10 Breeder/nipple Drinker
Application: Breeder Raising Shed Operation: Fully Automatic
High Light:

Parent Chicken Breeding Equipment


260Kg Chicken Breeding Equipment


3.0mm broiler automatic feeder

Product Description

Automatic Broiler Breeder Female Male Farm Equipment for Poultry House

Big Chain Breeder Poultry House Broiler Female Raising Equipment For Automatic Breeding Parent House


Automatic Poultry House Construction:


Item Name Materials Characteristics Material Grade Surface Treatment
Steel Column H shape,Box,Steel Pipe,Hot tolled sheet Q235B,Q345B Paint or Hot dip Galvanized
Steel beam H shape,Box,Steel Pipe,Hot tolled sheet Q235B,Q345B Paint or Hot dip Galvanized
Steel Bracing Steel Rod,Steel Pipe,Angle Steel Q235B,Q345B Paint or Hot dip Galvanized
Steel Purlin C or Z purlins(Thickness1.8mm~3.0mm) Q235B,Q345B Hot dip Galvanized
External Wall panels,Roof panels Single colorful corrugate steel sheet,sandwich panels with EPS,Rock wool,PU. Galvanized Steel+Painting Alu-zin 150g,Fluorocarbon pain
Steel buildings Door Slidding or Rolling door Steel or Aluminum sheet Paint or Hot dip galvanized
Steel buildings Windows Aluminum alloy-Glass,Aluminum alloy-shutter T=1.0-2.0mm Alloy
Skylighting panels FRP T=1.5mm-1.8mm Coefficient of thermal expansion:2.2x10-5/cm Light Tranmitar 85%
Ventilator Turbine ventilator on a ridge Steel,Stainless steel ,PC Paint or Hot dip Galvanized
Gutter Galvanized steel plate,Stainless steel plate T=2.0mm Hot dip galvanized
Downpipe PVC pipe,color steelpipe Y=0.5mm Dia110mm paint
Hight Bolt Ordinary ,High strength 10.9S,4.8S Hot dip galvanized,Steel
Ground bolts Steel RodM24,M27,M30,M33,M39,M42 10.9S Steel


Automatic Poultry House Equpment:


1. Main feed line system: Silo /manpower hopper is the beginning of main feed line.There is a feed sensor at the end of main feed line which controls motor on and off to achieve automatic feed delivery.
2. Automatic pan feeding line system: There is a feed sensor at the end of each feeding line which controls motor one and off to achieve automatic feed delivery to each feed pan.
3. Automatic Nipple drinking line system: supply clean water to each nipple steady, chicken can drink water from 360
4. Ventilation system: make chicken shed keep suitable temperature for different stage chicken
5. Environment control system: A variety of environment controllers are customized from Israel,it can reach a most advanced control leave in poultry house control.
6. Cooling pad system: The longitudinal way of cooling-fan ventilation way is the most economical and effective way to reduce temperature of chicken house in summer.
7. Fogging system: It is effectively tools for cooling,damping,dedusting and disinfecting the house.
8. Heating system: In winter or chicks,it make chicken house has a suitable temperature.




Female Breeder Chain Feeding System:


Driving motor:

use cycloidal-pin wheel reduce device, more stable and reliable convey feed equality, reduce noice than toothed wheel.

Feed trough bracket and connection:

They are liftable. We can adjust their height according different breeding stages. Bracket surface use hot galvanized

process, anti-corrosion, more suitable for poultry house environment.

90 degree corner wheel:

The wheel is after special hardening process, alloy bearing don't need oiling, have good wear resistance and long service


Feed trough:

made of wear-risistant and anti-rust material, have 44mm wide limited food grill, which can separate the hens and roosters

apart effectively, the limited food grill distance can also be customized.


imported from South Africa, have strong feed delivery speed, can reach 36m/minute.


We have 260Kg main hopper and 100Kg vice hopper, they are made of high quality galvanized sheet, there is cover plate

between hopper and trough interface, which is easy to adjust the height of feed level and to prevent feed spill.




Broiler Automatic Feeder Chicken Breeding Equipment 0


Coner wheel:

90 degree hgih strength angle wheel, drive gear and corner wheel are made of wear resistant material, and after hgih frequency quenching, high hardness, wear resistance.

Chain: South Africa champion brand chain, the world's best chain, high tensile strength, long service life.


Broiler Automatic Feeder Chicken Breeding Equipment 1



Breeders nipple drinking system:


1). Outside shell is made of pure engineering plastic, inner valve rod is made of stainless steel.

2). Feeding capability: 8-10 birds/drinker.

3). All nipples are anti-rusting, service life over 10 years.

4). Double-sealing structure, with good seal ability, avoid water leakage and its bad influence to chicken farm.

5). Valve rod is movable in 360 degree, it's suitable for all breeders to drink, from day-old chicks to adult chickens.

Pressure regulator( double barreled with large flow capacity)

1). Good regulating stability, high switching performance.

2). Sufficient water supply.

3). Recoil cleaning with good cleaning result, save time& water.

4). Good quality movable valve, easy to change

Waterline front system:

Front part is controller of water, it's main function is to adjust water supply pressure and stabilizing drinking volume.

This part is usually installed in control room.

1). Pressure regulator: make sure to supply stable water to drinking line. Anti-backlash device can discharge the

impurity in pipe.

2). Filter: clean water and avoid blocking nipples.

3). Water meter: measure water usage volume.

4). Doser: add medicine exactly to prevent disease.

Lifting& suspension system:

Correct height for drinking system is very important for chicken( both higher and lower can result chicken bone's

distortion, which is bad for chicken growth, also lead to water waste), it's easy to adjust drinking line height by winch.

Water display level tube:

Use high transparency& impact resistant meterial, it's sturdy and durable, easy to watch water level, easy to take down

and clean with this advanced design.



Automatic Breeder Nest System:



1. 1520(length)*1285(wideth)*1020 (height)mm size(with prevent perching line), 24 holes design, one nest hole size 380*250mm.


2. High quality 0.5mm Galvanized plate ,one set weight 47kg, zinc weight 275g/m2, reach international standards.


3. Use high-quality PVC pedal ,smooth and no thorns,better than wood.

4.The plastic trays made of modified material, strong and good toughness. Also can be galvanized sheet.



  • PVC don't deform, but the wood will bends after use some time.
  • PVC don't have burr, won't hurt chicken feet.
  • The wood is easy to produce the bacteria, PVC won't.
  • PVC material don't need fumigation, reduce the cost for exporting.
  • The using life of PVC is longer than wood.

Broiler Automatic Feeder Chicken Breeding Equipment 2



System Pictures:



Broiler Automatic Feeder Chicken Breeding Equipment 3



Broiler Automatic Feeder Chicken Breeding Equipment 4



Broiler Automatic Feeder Chicken Breeding Equipment 5
