Pure Pp Poultry Pan Feeder Chicken 450kg/H

Basic Information
Place of Origin: China
Brand Name: XDA
Model Number: XDA-F06
Minimum Order Quantity: 1000pcs
Price: 1.8 - 2.8 USD
Packaging Details: Standard
Delivery Time: 10 days
Payment Terms: L/C, T/T
Supply Ability: 15000pcs per day
Detail Information
Name: Poultry Farming Chicken Feeder Material: High Quality 100% Pure PP
Application: Chicken, Hen, Chick, Duck, Goose, Bird, Quail, Pigeon Advantage: Complete Automatic Broiler Feeding Equipment
Contact: Whatsapp 008618830728667 Keyword: Chicken Pan Feeder
High Light:

pure pp poultry pan feeder


450kg/h poultry pan feeder


pure pp chicken pan feeder

Product Description

Automatic Poultry animal Farm Floor Raising Chicken Broiler Breeder Drinker System Pan Feeder


Broiler Automatic feeding system

Consists of a driving device, a hopper, a conveying pipe, an auger, trays, a suspension lifting device, an anti-perching device and a feed sensor. The main function of the system is to convey the feed in the hopper into each tray to ensure the eating of the broiler and automatically control the conveying opening/closing of the motor by the material level sensor to feed automatically.


Parameter of Feeding Line
1. High-quality special driving motor Italy Transtechno
Power: 0.75kw, voltage: 380V, frequency: 50HZ, three-phase AC current
2. V-shaped Bin (With Hopper)
Bin Volume: 115L, hopper volume: 38L,
Material: hot-dip galvanized sheet
3, Feeding System 3M 4holes Feeding pipe
Diameter of conveying pipe: φ45mm
Material: Quality hot-dip galvanized steel pipe with the zinc coating amount of more than 275g/m2
Helical spring auger from South Africa feeding capacity: 450kg/h
4. Material level sensor from Israel: time delay range 0 to 2 hours


Product Name Chicken Broiler Breeder Pan Feeder and Drinker System
Material pp
Pan distance 3-4 pans/3m
Space between two grills 75-100mm
Transmission speed 450kg/h
Usage Livestock Feeding
Color Orange
Feature Save Breeding Cost
Type Livestock Equipment
Application Poultry Farm Chicken/Duck Feeding


poultry feeding

poultry feeding systemU56_.jpg1 (8).jpg
